Telephone Underside:
37. Base underside sticker information:
Certification – FCC,CE,ETL,ROHS
Version label
Model name
REN number
Disposal label
QC label
Series number
Warranty Void If Seal Broken label
38. Message Waiting selector switch
TYPE LR1 LR2
39. Non-Slip rubber feet (4)
39 37 38
Cordless Handset Charging Station:
40. Message Waiting indication
40 41. Cordless Handset
42. Handset Pop-Off Cover for
Battery compartment
43. Interchangeable Accent Piece,to
match custom cradle color
44. Battery Charging & Synchronization
programming indicator light
41 45. AC Power Plug-In.(back of stand)
46. Cordless Handset Charging Stand
Handset will charge regardless of
Whether it is placed with either front
or back showing
Power Adaptor:
47. Phone Line from wall goes
42 into Line receptacles
43 48. Line to Phone from Adaptor
44
45 47
46
48
