Handset – Telematrix 9600 Series Auto-Sync User Manual

Page 3

background image

3

1 2 3 4 5 6a
24 25 26




6b
7
27

28

29
8
30

9
31
11

32a 10a
33
10b

32b
34




36 35 36
22 23 20 19 21 18 17 16a 16b 15 14 13 12

Handset:

24. Cordless Handset –Handset can be synchronized with base with a few simple steps
25. Message Waiting Indicator,blinks when message is waiting
26. ADA Compliant Handset Speaker
27. Handset Faceplate & Plastic Overlay
28. Line Selector key – Line 2 On/Off with LED indication
29. Hold/Conf.Handset key,and remote release
30. Line Selector key – Line 1 On/Off with LED indication
31. Handset Dial Pad
32a.Handset Volume Up (5-Step)
32b.Handset Volume Down (5-Step)
33. Last Number Redial key
34. Flash key
35. Handset Microphone
36. Charging Location Contacts (Handset must be face down to charge)
