Section 3: 520V, CB, 150A & 600 – 2500A

EMC Filters
Phase: 3
Current: 150 A; 600 to 2500 A
Voltage: 520/300 V AC, 50/60 Hz
Termination: Copper Bus

Part Numbers:
KRF0150ACB
KRF0600ACB
KRF1000ACB
KRF1600ACB
KRF2500ACB

Construction
• 3-line filter
• Metal case

Features
• Optimized leakage current
• Easy to install
• Very compact design
• Optimized for operation under full load
• Low weight

• UL, cUL approval

Applications
• Frequency converters for motor drives
• Wind farms
• Power supplies

Terminals
• Busbars

Marking
Marking on component:
Manufacturer’s logo, ordering code,
rated voltage, rated current, rated temperature,
climatic category, date code
