S T A N D A R D O P T I O N ( S )
Standard Option (S) HGP IOM Manual 15
Product Technical Specifications
Tables 1 & 2 list the major technical specifications for the HGP Filter.
Table 1 – HGP Technical Specifications
Voltage ratings 480V, 3 phase, 60 Hz
kVar ratings 1.3 to 270 kVar depending on voltage.
Load types 3-phase diode bridge rectifier loads such as PWM AC drives
Load power range 5 -900 HP
Current ratings
The included series reactors can tolerate 200% of rated current for at
least 3 minutes.
SCCR (short circuit current
rating)
Standard rating is 100kA.
Maximum elevation 3,000 feet (1,000 meters) as standard.
Maximum ambient operating
temperature
50°C (122°F) – Open Panel; 40°C (104°F) – Enclosed Panel.
Product must be equipped with special cooling provisions for
operation above this temperature.
Maximum ambient storage
temperature
60°C (140°F)
Maximum humidity,
operating or storage
95%, non-condensing.
Enclosure options
UL Type 1 enclosure
UL Type 3R enclosure
Agency approvals or
certifications
UL and cUL Listed to UL508A
Insertion Impedance +/- 10% at full load current
Fusing and protection: All units have internal fuse protection for the harmonic filter circuit.
Table 2 – HGP Watts loss
HP Heat Loss (watts) HP Heat Loss (watts)
5 140 200 1600
7.5 150 250 1800
10 175 300 2100
15 250 350 2200
20 275 400 2600
25 250 450 2800
30 300 500 3100
40 500 600 2700
50 550 700 2900
60 675 800 3000
75 650 900 3300
100 750 200 1600
125 1000 250 1800
150 1200
