Part Number Encoding
Figure identifies the significance of each character in the HGP part number. The example part number,
HGP0150AW1S0000 designates an HGP filter that is rated 150 HP, 480 volts, 60 Hz. It includes a line
reactor, tuning reactor, and capacitors in a UL Type 1 enclosure. It is designed for use with a 150 HP
drive.
Figure 1 – HGP Part Number Encoding
F
G
Option:
0 - Standard
0 - Standard
Option:
0 - Typical Voltage Distortion
Option:
1 - High Voltage Distortion
0 0
Option:
0 - Standard
Option:
- Fuse Monitor with Contactor
- Fuse Monitor without Contactor
W - 60 Hz
Enclosure:
0 - Open
Frequency:
Horse Power:
Voltage Rating:
A - 480 V
0 0 0
Series:
A W 1 S P 1 5 0 G H
1 - Type 1
C - Contactor
S - Standard
3 - Type 3R
