72
Model DRL1600 DRL800 DRL400
Performance PENTAPLEX
Display Speed (NTSC / PAL) 480 / 400 fps 240 / 200 fps 120 / 100 fps
Recording
Speed
(NTSC / PAL)
D1(704*480)/(704*576) 120 / 100 fps 120 / 100 fps 120 / 100 fps
2CIF(704*240)/(704*288) 240 / 200 fps 240 / 200 fps 120 / 100 fps
CIF (352*240)/(352*288) 480 / 400 fps 240 / 200 fps 120 / 100 fps
Video In
Signal Level 1.0 Vpp Composite (
±10%)
Channel 16 Ch (BNC) 8 Ch (BNC) 4 Ch (BNC)
Video Out
Main Display HDMI, VGA, Composite(CVBS)
Main Display Resolution 1920x1080p, 1920x1080i, 1440x900 60Hz, 1280x1024 60Hz
Spot 1 1 -
Audio Input / output 4 / 1 4 / 1 1 / 1
Alarm Input / output 8 / 2 8 / 2 4 / 1
Details
Screen
Display Split 1, 4, 7, 9, 10, 13, 16 1, 4, 7, 9 1, 4
Interface Graphic User Interface
Video
Format NTSC / PAL Auto detection
Codec H.264 Advanced
Recording type Schedule / Continuous / Event (Motion, Alarm)
Storage
Interface type SATA II
HDD / Capacity Up to 2 HDD’s 1 HDD
Connectors USB port USB port * 2
Function
Live Display
OSD On / Off
Border Color/ Digital Zoom Selectable / Up to 4X
Cameo Camera Adjustment / Camera position change / Freeze / Audio on
Motion
Area Adjustable GRID (22 X 15)
Sensitivity 5 Level motion detection
System
Hidden Video Video is hidden in Live view but it is recorded
Private Zone Block the private zone in live camera view
Auto Time Synch By NTP (Network Time Protocol)
Firmware Update Via USB & Auto firmware upgrade via Network
SMART Alarm Auto Detect & Monitoring HDD’s problem
Event
Source Motion / Alarm In / Video loss
Action E-Mail notification, Log Send message to Remote, Buzzer, Pop Up, Alarm out, PTZ preset
Pre/Post Alarm Yes (Up to 60 sec / Up to 100 sec)
Record
Resolution By each camera for different resolution setting (CIF/2CIF/D1)
Quality 4 Levels ( Low / Normal / High / Highest )
Search
Quick / Event search Search by time with calendar / Search by event
Repeat search Select specific time period and playback repeatedly
Panorama search Frame by frame
Smart search Search only event and playback without interval
CAMEO Live monitoring during playback, Playback camera change, Freeze and Digital zoom
Backup file format / Media DVR Format / DVD or USB device
Network
Protocol Static IP, DHCP, DDNS
Physical / Mac Layer RJ45 (10/100 Mbps), Ethernet
Browser SMS, Web Viewer, Smart Phone Viewer (Android, I-phone)
Environment
Operating Temperature / Humidity 0~40 ℃ / 20~80% RH
Dimension / Weight 350(W) X 258(D) X 70(H) / 6Kg (without HDD) 295(W) X 182(D) X 35(H) / 1.2Kg
Power Requirement / Consumption AC 100V – 220V (50Hz-60Hz) / 120W AC 100V – 220V (50Hz-60Hz) / 40W
8.3 Specification
8. APPENDIX
