Service Mode
13-4 5975288 BARCOGRAPHICS 8200 110497
Service Mode
13-4 5975288 BARCOGRAPHICS 8200 110497
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJ. ADDRESS
CHANGE BAUDRATE PC
RESET LAMP RUNTIME
LAMP RUNTINE HISTORY
MORE...
Select with or
then
to return.
SERVICE
PANEL ADJUSTMENTS
PRESET INPUT BALANCE
60Hz TRACKING
I2C DIAGNOSIS
MORE...
Select with or
then
to return.
PANEL ADJUSTMENT
RED COARSE
FIELD FLICKER
BLACK LEVEL TOP
BLACK LEVEL BOTTOM
GAIN TOP
GAIN BOTTOM
Change color+pattern
with or
Select with or
then
to return.
PRESET INPUT BALANCE
WHITE BALANCE
Select with
to return
Adjust
red with or
blue with or
60 Hz TRACKING
-15 +15 0
I2C DIAGNOSIS
D CA
LCD DRIVER SC76013 E2H # # #
LCD DRIVER SC76013 E4H # # #
LCD DRIVER SC76013 ECH # # #
LCD DRIVER SC76013 EEH # # #
LCD DRIVER TDA8444 48H # # #
LCD DRIVER TDA8444 4AH # # #
INPUT SELECTOR TDA8444 46H # # #
INPUT SELECTOR PCF8574A 7EH # # #
DECODER
PCF8574 4EH # # #
DECODER SAA7151B 8AH # # #
DECODER SAA7152 B2H # # #
DECODER SAA7192A E0H # # #
LAMP DRIVER PCF8574A 72H # # #
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJ. ADDRESS
CHANGE BAUDRATE PC
RESET LAMP RUNTIME
LAMP RUNTINE HISTORY
MORE...
Select with or
then
to return.
SERVICE
PANEL ADJUSTMENTS
PRESET INPUT BALANCE
60Hz TRACKING
I2C DIAGNOSIS
MORE...
Select with or
then
to return.
PANEL ADJUSTMENT
RED COARSE
FIELD FLICKER
BLACK LEVEL TOP
BLACK LEVEL BOTTOM
GAIN TOP
GAIN BOTTOM
Change color+pattern
with or
Select with or
then
to return.
PRESET INPUT BALANCE
WHITE BALANCE
Select with
to return
Adjust
red with or
blue with or
60 Hz TRACKING
-15 +15 0
I2C DIAGNOSIS
D CA
LCD DRIVER SC76013 E2H # # #
LCD DRIVER SC76013 E4H # # #
LCD DRIVER SC76013 ECH # # #
LCD DRIVER SC76013 EEH # # #
LCD DRIVER TDA8444 48H # # #
LCD DRIVER TDA8444 4AH # # #
INPUT SELECTOR TDA8444 46H # # #
INPUT SELECTOR PCF8574A 7EH # # #
DECODER
PCF8574 4EH # # #
DECODER SAA7151B 8AH # # #
DECODER SAA7152 B2H # # #
DECODER SAA7192A E0H # # #
LAMP DRIVER PCF8574A 72H # # #
