P121-2/P121LC-2/P121RC-2/P131-2 Zero Clearance Direct Vent Gas Fireplace

INSTALLATION

Option 1:

REMOTE CONTROL

Can be used with Option 2 or 3 but

not both.

Use the Regency

®

Remote Control Kit approved

for this unit. Use of other systems may void your
warranty.

The remote control kit comes with a hand held
transmitter, a receiver and a wall mounting plate.

1) Choose a convenient location on the wall to

install the receiver and the receptacle box
(protection from extreme heat is very important).
Run wires from the fi replace to that location.
Use the Thermostat Wire Table.

2) Connect the two wires to the gas valve. See

diagram below.

Option 2:

WALL SWITCH

Can be used with Option 1 or 3

but not both.

1) Run the supplied 15' of wire through the back

gas inlet opening. Be careful not to damage
wire.

Note: We recommend a maximum of 15' of

wire but if you wish to go with a longer
run, use the Thermostat Wire Table.

2) Connect the wire to the supplied wall switch

and install into the receptacle box.

Thermostat Wire Table

Option 3:

WALL THERMOSTAT

Can be used with Option 1 or 2 but

not both.

A wall thermostat may be installed if desired, connect
the wires as per the wiring diagram. Use the table
below to determine the maximum wire length.

Note: Preferable if the thermostat is installed
on an interior wall.

Regency

®

offers an optional programmable

thermostat but any 250-750 millivolt rated non-
anticipator type thermostat that is CSA, ULC or
UL approved may be used.

3) Install 3 AAA alkaline batteries in transmitter

and 4 AA alkaline batteries in the receiver.
Install the receiver and its cover in the wall.
Switch the remote receiver to "remote" mode.
The remote control is now ready for operation.

CAUTION

Do not connect millivolt all

switch wire to a 120V wire.

CAUTION

Do not connect millivolt

wall thermostat wires

to a 120V wire.

Recommended Maximum Lead Length

(Two-Wire) When Using Wall

Thermostat (CP-2 System)

Wire Size

Max. Length

14 GA.

50 Ft.

16 GA.

32 Ft.

18 GA.

20 Ft.

20 GA.

12 Ft.

22 GA.

9 Ft.

CAUTION

Do not connect millivolt

remote control wires to a

120V wire.
