Installation – Regency Hampton GCI60 Large Pellet Insert TECHNICAL MANUAL User Manual
Page 17
Installation
recommended
- t
hrough
W
all
W
ith
v
ertical
r
iSe
and
h
orizontal
t
ermination
i
nStallation
:
figure 12: Venting horizontally with rise.
NOTE - This venting configuration is only for use with the Built-In installation.
Wall framing
Wall thimble
Termination cap
Vertical section
of vent pipe
Clean
out tee
Wall strap
90°elbow
Horizontal
frame for
thimble
Hampton GCI60 Cast Pellet Insert Technical Manual
17
