Service manual WM70.C
25
This document must not be copied without
our written pemission, and the contents
thereof must not be imparted to a third party
nor be used for any unauthorized purpose.
Contravention will be prosecuted.
Asko Appliance AB
CIRCUIT DIAGRAM WM70.C WC US/CA
80 893 65 - 01
WIRES IN ALL MACHINES
INTERNAL CONNECTION
RESISTANCES AT ROOM TEMPERATURE (CA. 20°C/68°F)
VALUES WITHIN +/-10% ARE REGARDED AS NORMAL COMPONENT
F: RADIO INTERFERENCE SUPPRESSION FILTER 680K Ohm
EL: HEATING ELEMENT 25 Ohm
AP: DRAIN PUMP 50 Hz 144 Ohm
AP: DRAIN PUMP 60 Hz 76 Ohm
AV: DRAIN VALVE 110/134 Ohm
LL: DOOR LOCK, 1-2 122 Ohm
NTC: THERMISTOR 6.1 - 3.8 K Ohm
IV 1: INLET VALVE 1 3.7 K Ohm
IV 2: INLET VALVE 2 3.7 K Ohm
IV3: INLET VLAVE 3 3.5 K Ohm
MO: MOTOR, 1-3 4,3±7% Ohm
1-2 4,3±7% Ohm
2-3 4,3±7% Ohm
MCU: MOTOR CONTROL UNIT
N: PRESSURE SWITCH
TS: PRESSURE SENSOR
TG: TACHO GENERATOR
BA: CONTAINER
INKB: INCOMING GROUND
CI: COMMUNICATIONS INTERFACE
CM: COIN METER CABLES
IV2 IV1
NTC
F
TS
AP/AV
LL
MO
MCU
3
2
1
CABLE POSITIONS
1: MOTOR COMMUNICATION
2: THERMISTOR
3: INLET VALVES
4: DOOR LOCK, DRAIN PUMP, PREASSURE SWITCH
6: COMMUNICATION INTERFACE
7: COIN COLLECTOR
8: POWER
9: HEATING ELEMENT, PREASSURE SWITCH
10: MOTOR POWER
3
1
2
TG
N14 N12 N16 N11 E L1 N R 43 R 44 R 34 R 33 R 23 R 24 R A R B EL INKB BA E L2 F RP AV BO WIRES IN SOME MACHINES F1 F2 1 Phase, 16 A 2011-04-14 SERVICEMENU TURN OFF POWER (S1) WAIT FOR AT LEAST 5 SEC HOLD S4 TURN ON POWER (S1) PRESS S4 5 TIMES TO ENTER SERVICE MENU PRESS DOOR OPENING (S5) TO CHANGE MENU STEP ROTATE DIAL TO CHANGE IN STEP PRESSING START/STOP (S4) STORES AND EXITS SERVICE MENU USER SETTINGS MENU TURN OFF POWER (S1) WAIT FOR AT LEAST 5 SEC HOLD S5 TURN ON POWER (S1) PRESS S5 5 TIMES TO ENTER MENU COMMON PHASE S1 S5 S4 R33 N L1 R43 / R23 L P1 P2 P3 FUSE FUSE This document must not be copied without our written pemission, and the contents thereof must not be imparted to a third party nor be used for any unauthorized purpose. Contravention will be prosecuted. Asko Appliance AB CIRCUIT DIAGRAM WM70.C WC US/CA 80 893 65 - 01 WIRES IN ALL MACHINES INTERNAL CONNECTION RESISTANCES AT ROOM TEMPERATURE (CA. 20°C/68°F) VALUES WITHIN +/-10% ARE REGARDED AS NORMAL COMPONENT F: RADIO INTERFERENCE SUPPRESSION FILTER 680K Ohm EL: HEATING ELEMENT 25 Ohm AP: DRAIN PUMP 50 Hz 144 Ohm AP: DRAIN PUMP 60 Hz 76 Ohm LL: DOOR LOCK, 1-2 122 Ohm NTC: THERMISTOR 6.1 - 3.8 K Ohm IV 1: INLET VALVE 1 3.7 K Ohm IV 2: INLET VALVE 2 3.7 K Ohm IV3: INLET VLAVE 3 3.5 K Ohm MO: MOTOR, 1-3 4,3±7% Ohm 1-2 4,3±7% Ohm 2-3 4,3±7% Ohm MCU: MOTOR CONTROL UNIT N: PRESSURE SWITCH TS: PRESSURE SENSOR TG: TACHO GENERATOR BA: CONTAINER INKB: INCOMING GROUND CI: COMMUNICATIONS INTERFACE CM: COIN METER CABLES IV2 IV1 NTC F TS AP/AV LL MO MCU 3 1 CABLE POSITIONS 1: MOTOR COMMUNICATION 2: THERMISTOR 3: INLET VALVES 4: DOOR LOCK, DRAIN PUMP, PREASSURE SWITCH 6: COMMUNICATION INTERFACE 7: COIN COLLECTOR 8: POWER 9: HEATING ELEMENT, PREASSURE SWITCH 10: MOTOR POWER 3 1 2 TG N14 N12 N16 N11 E L1 N R 43 R 44 R 34 R 33 R 23 R 24 R A R B EL INKB BA E L2 F RP AV BO WIRES IN SOME MACHINES F1 F2 1 Phase, 16 A 2011-04-14 SERVICEMENU TURN OFF POWER (S1) WAIT FOR AT LEAST 5 SEC HOLD S4 TURN ON POWER (S1) PRESS S4 5 TIMES TO ENTER SERVICE MENU PRESS DOOR OPENING (S5) TO CHANGE MENU STEP ROTATE DIAL TO CHANGE IN STEP PRESSING START/STOP (S4) STORES AND EXITS SERVICE MENU USER SETTINGS MENU TURN OFF POWER (S1) WAIT FOR AT LEAST 5 SEC HOLD S5 TURN ON POWER (S1) PRESS S5 5 TIMES TO ENTER MENU COMMON PHASE S1 S5 S4 R33 N L1 R43 / R23 L P1 P2 P3 FUSE FUSE
AV: DRAIN VALVE 110/134 Ohm
