Service manual WM70.C
11
2 Settings 21 Water
inlet Cold Valid for products manufactured before February 2012.
Hot
21 HWC Off (default) Valid for products manufactured from February 2012.
On
22 Max RPM 400 rpm This function only works for programmes Pr1-Pr19.
600 rpm
800 rpm
1000 rpm
1200 rpm
1300 rpm
1400 rpm
1500 rpm
1600 rpm
23 Drain Pump
Valve
24 Show
temp Temp Off Only applies to the disinfection programmes (Pr17-Pr19)
Temp On
25 Change
temp Pr1-Pr25 This can be changed in steps of 1°C between -10°C to +10°C.
You cannot set a total temperature that exceeds +92°C.
26 Programs Pr1-Pr28 Select “On” or “Off”
Programmes can be activated/deactivated. A deactivated
programme is not shown on the display.
A maximum of 10 programmes can be shown on the display in
programme mode. If more than 10 programmes are activated,
then only the first ten activated programmes are shown on the
display.
If all the programmes have been deactivated, the display only
shows “Pr1”.
If the machine is Swan-labelled, “Pr1” and “Pr2” are always
activated/On.
27 Spin time 0-300 sec • Extend or shorten the spin time: 0-300 sec.
• If “0 sec” is selected, the pre-programmed spin time is used.
• If a time in the interval “1 sec” to “300 sec” is selected, this
time is added to the pre-programmed spin time.
• This function only works for programmes Pr13 and Pr14.
28 Coin Coin Off See the wiring diagram for the correct connection and
functionality of a slot meter.
Coin On
29 Reset Only
production
reset Used only in production
210 Off (default) When On is choosed it shall be possible to temporally change
to language in the machine. The language shall return to selected
machine language (selected in the user menu) when the
program is finished. This menu step is placed after program 28.
On
Return Press the Key button (S5) to return to 2 Settings.
Service menu content (cont.)
