Summit WMC64P Service Manual - Manual (Page 10)

Service manual WM70.C
10
1 Service 11 Info SP: XXXX Date the software was programmed (Year_Week)
CM: XXXX Date of manufacture of the control unit (Year_Week)
SW: Software version
SW: Software version
NC: Number of cycles/programmes run
NC 1: Number of cycles for Programme 1
NC 2: Number of cycles for Programme 2
NC 28: Number of cycles for Programme 28
12 Fault
scenarios Fault 1 Shows current fault. The display shows Fault name_Programme
number_Number of cycles_ Index number.
Example: Thermistor fault_Pr5_9_(1)
Fault 2
Fault 3
13
Diagnostics Test
Test valve 1
Inlet valve 1 is open.
Test valve 2 Inlet valve 2 is open.
Test valve SM Inlet valve 1 and 2 are open.
Test valve 3
Inlet valve 3 is open.
Test heater Heater on up to max. 60°C.
Test motor The motor normally runs at 49 rpm.
Test drain The drainage pump runs.
Test spin The machine runs a spin sequence, the drainage pump runs.
Test door The door lock is activated and the door opens. Returns to the
programme menu.
14 Total
reset The machine is restored to its factory settings. Returns to the
programme menu after Total reset.
15 ABC
reset The custom programmes (Pr20-Pr22) are reset. Returns to the
programme menu after ABC reset.
Return Press the Key button (S5) to return to 1 Service.
Service menu content
