Schwank SCH-90 Construction - Manual (Page 3)

GP-MCH9-BX-10C
SCH-90 / IC-90 Manual
R.D: Aug 2006
RL:10C
KH
Page 3
TECHNICAL SPECIFICATIONS
NG LP
Input (BTU) - Normal Altitude: 90,000 87,500
- High Altitude: 81,000 79,545
Height (inches): 36” Width (inches): 24”
Ignition controls: standing Thermostat: finger
pilot touch
control
Tip-over switch: 35º Gas inlet: NG-1/2” LP-3/8”
Clearances to: 24” (top) Minimum gas: 6.3” (NG)
Combustibles 48” (side) Pressure (W.C.) 11.3” (LP)
No electric power required. Also available in 200,000 BTU
TABLE OF CONTENTS
— INFORMATION AND SAFETY LABELS
4
1.0 INSTALLATION REQUIREMENTS
6
1.1 GENERAL INSTRUCTIONS
6
1.2 GAS SUPPLY LINE/GAS PRESSURE 7
1.3 VENTILATION REQUIREMENTS 7
1.4 CLEARANCES TO COMBUSTIBLES 7
1.5 MOUNTING INSTRUCTIONS 8
1.6 LIGHTING/SHUTDOWN INSTRUCTIONS 9
1.7 LIGHTING/SHUTDOWN INSTRUCTIONS 9
1.8 THERMOSTATIC CONTROL 10
2.0 MAINTENANCE
10
3.0 REPLACEMENT PARTS
12
3.1 SCH-90 / IC-90-N/L 12
3.2 SCH-90-M / IC-90-M-N/L 14
4.0 WARRANTY
16
