Schwank SCH-90 Construction - Manual (Page 14)

GP-MCH9-BX-10C
SCH-90 / IC-90 Manual
R.D: Aug 2006
RL:10C
KH
Page 14
3.1 REPLACEMENT PARTS FOR SCH 90-M- N/L / IC-90-M-N/L
TABLE 3: REPLACEMENT PARTS LIST
(REFERENCE PAGE 9)
ITEM NO. PART NAME SCH-90-N SCH-90-L
1 SHROUD JH-0613-XX JH-0613-XX
2 WIRE GUARD JH-0610-XX JH-0610-XX
3 MANTLE JH-0433-XX JH-0433-XX
4 VENTURI ASSEMBLY JH-0615-XX JH-0615-XX
5 BURNER GASKET JH– 0437-FF JH-0437-FF
6 FLAME SCREEN RETAINER RING JH-0439-XX JH-0439-XX
7 FLAME SCREEN JH-0441-XX JH-0441-XX
8 MILLIVOLT GAS VALVE JH-0414-NG JH-0414-LP
9 MAIN ORIFICE JH-0418-NG JH-0418-XX
10 PILOT BURNER (NOT SHOWN) JH-0406-XX JH-0406-XX
11 PILOT ORIFICE HONEYWELL (NOT SHOWN ) JH-0407-NG JH-0407-LP
12 PILOT TUBE JH-0463-XX JH-0463-XX
13 MILLIVOLT GENERATOR - POWERPILE JH-0504-XX JH-0504-XX
14 BLACK WIRE ASSEMBLY (NOT SHOWN) JH-0465-XX JH-0465-XX
15 THERMOSTAT ASSEMBLY JH-0414-TS JH-0414-TS
16 VALVE INLET JH-0640-XX JH-0641-XX
17 QUICK CONNECT JH-0601-ML HJ-0591-ML
18 8” RETAINER GRIPS (16” AVAILABLE) JH-0936-XX JH-0936-XX
19 REGULATOR ASSEMBLY (NOT SHOWN) — JH-0903-RG
20 HOSE ASSEMBLY—(NOT SHOWN) JH-0902-XX JH-0902-LP
21 FILTER RETAINER JH-0935-XX JH-0935-XX
22 FILTER JH-0933-XX JH-0933-XX
UPPER RING PORTION OF GUARD Only JH-0610-TP JH-0610-TP
LOWER LEGS PORTION OF GUARD Only JH-0610-BM JH-0610-BM
