6
Remote Control Operation -- Quick Start
NOTE: When transmitting a command from the remote control to
the unit, be sure to point the control toward the right side of the
unit. the unit will confirm receipt of a command by sounding an
audible beep.
1. Turn the unit on by pushing the ON/OFF button.
2. If there is a preference for temperature settings to be dis-
played in _F rather than _C (default), push the recessed F/C
button once using a paper clip or similar object.
3. Select the desired mode by pushing the mode button.
AUTO COOL DRY HEAT FAN
NOTE: Cool only units have no heat mode.
4. Select the temperature set point by pointing the control to-
ward the unit and pressing the increase/decrease temperature
set point buttons until the desired temperature appears on
screen.
5. Select the desired fan speed by pressing the FAN SPEED
button to select desired fan speed.
NOTE: If unit is operating in Dry mode, AUTO fan speed will be
displayed.
6. Set the airflow direction. When the unit is turned on, the
louvers default to the cooling or heating position. The user
can adjust louver position by pushing the air direction but-
ton or have continuous louver movement by pushing the
swing button.
Emergency Operation
If the remote control is lost, damaged, or the batteries are
exhausted, the MANUAL button can be used to run the unit.
Open the front cover panel and press the MANUAL button once
briefly when the system is off.
To stop emergency operation, push the MANUAL button twice or
operate the remote control.
If the MANUAL button is only
pushed once, the system will enter TEST mode and run for 30
minutes.
Manual button
A07364
The set conditions of emergency operation are as follows:
S Preset set point: 76_F (24_C)
S Fan speed: AUTO
S Discharge air direction: Pre--set position based on operation in
“Cool”or “Heat” mode.
REMOTE CONTROL FUNCTIONS
Pressing the On/Off Button
SET TEMP.
C L O C K
SPEED AUTO
AUTO
ON/OFF
INDICATOR
A08034
When the air conditioner is not in operation, the remote control
will display the last set point, mode and time.
S Press the On/Off button to start the unit.
-- The unit will start in the last operating mode and set
point. The ON/OFF indicator will appear.
S Press button On/Off to stop the unit.
-- All indicator lights on the unit will go out, and the remote
control will display the set point, mode and time.
NOTE: If the On/Off button is pressed too soon after a stop, the
compressor will not start for 3 minutes due to the inherent
protection against frequent compressor cycling. The unit will only
emit an audible beep when the signals are received correctly.
Selecting an Operating Mode
Use the Operating Mode button to select one of the available
modes.
SET TEMP.
C L O C K
SPEED AUTO
OPERATING MODE
AUTO COOL DRY HEAT FAN
AUTO COOL DRY HEAT FAN
A08034 / A07548
Setting the Room Temperature Set Point
Pressing the increase temperature set point and decrease
buttons will raise or lower the temperature.
The unit will confirm signal receipt with a beep and the value of
the set temperature on the display will change accordingly.
The temperature can be set between 62_F (17_C) and 88_F
(31_C).
NOTE: In Cooling mode, if the temperate selected is higher than
the room temperature, the unit will not start. The same applies for
the Heating mode if the selected temperature is lower than the
room temperature.
