S&S Cycle Ignition System For All 1999–03 Carbureted Harley-Davidson Twin Cam 88 Engines User Manual
Page 10
10
For more details, visit http://www.sscycle.com/software/guardian/
NOTES: Before purchasing the S&S IST Guardian™ Diagnostic System (P/N 55-5075) note that the software is only compatible with Windows® 2000/XP/
Vista/7 32-bit systems. It will not work on 64-bit operating systems.
Also, be aware that the Guardian system is only compatible with the S&S IST ignition module. It will not work with stock Harley-Davidson® or other
aftermarket modules.
Picture 11
Picture 12
Note position of connector lock
Pin #1
Pin #2
