67
N Wireless Router
sections table of contents 1 2 3 4 5 6 8 9 10 7
MaNUally CoNfIgURINg NeTWoRK seTTINgs
Manually Configuring Network settings in Windows 2000, NT, or XP
1� Click “Start”, “Settings”, then “Control Panel”.
2� Double-click on the “Network and dial-up connections” icon
(Windows 2000) or the “Network” icon (Windows XP).
3� Right-click on the “Local Area Connection” associated with your
network adapter and select “Properties” from the drop-down menu.
5� If “Use the following IP address” (2) is selected, your Router will
need to be set up for a static IP connection type. Write the address
information the table below. You will need to enter this information
into the Router.
(1)
(2)
(3)
6� If not already selected, select “Obtain an IP address automatically”
(1) and “Obtain DNS server address automatically” (3). Click “OK”.
your network settings are now configured for use with the Router�
4� In the “Local Area Connection Properties” window, click “Internet
Protocol (TCP/IP)” and click the “Properties” button. The following
screen will appear:
