18 • 65-2394RK-CH4-4 Combustible Gas Transmitter
Returning to Normal Operation
1. Remove the voltmeter leads from the amplifier test points.
2. Disconnect the calibration cup/splash guard’s flexible tubing from the regulator.
NOTE: Do not disconnect the flexible tubing from the calibration cup/splash guard.
3. Secure the amplifier junction box cover to the junction box.
4. When the controller display reading falls below the alarm setpoints, return the
controller to normal operation.
5. Verify that the controller display reading decreases and stabilizes at 0 %LEL.
6. Store the components of the calibration kit in a safe and convenient place.
Parts List
Table 5 lists replacement parts and accessories for the combustible gas transmitter.
Table 5:Parts List
Part Number Description
06-1248RK Sample tubing (3/16 in. x 5/16 in.; specify length when ordering)
18-0400RK-01 Junction box with spacers
57-1053RK Amplifier with gasket (specify detector part number when ordering)
61-0190RK-CH4 Methane infrared LEL detector
65-2394RK-CH4-4 Methane transmitter (includes detector, two junction boxes, and amplifier)
71-0277RK 65-2394RK-CH4-4 Combustible Gas Transmitter Operator’s Manual
(this document)
81-0004RK-01 Steel calibration cylinder, 50% LEL propane in air, 34-liter
81-0012RK-01 Steel calibration cylinder, 50% LEL methane in air, 34-liter
81-0076RK-01 Steel calibration cylinder, zero emission air, 34-liter
81-1050RK Regulator, 0.5 liter/minute; with pressure gauge and flow control knob, for 17
liter and 34 liter steel calibration cylinders
81-1103RK-01 Calibration cup/splash guard, with diffuser holes
81-F002RK-LV Calibration kit, includes regulator, sample tubing, calibration cup, and 34 liter
50 %LEL methane in air steel calibration cylinder
81-F006RK-LV Calibration kit, includes regulator, sample tubing, calibration cup, and 34 liter
50 %LEL propane in air steel calibration cylinder
82-0006RK Pot adjust screwdriver, for calibration
