Black – RKI Instruments 65-2394RK-CH4-4 User Manual
Page 13
65-2394RK-CH4-4 Combustible Gas Transmitter • 9
Figure 4: Wiring the Amplifier to a Controller
10. If shielded cable is used, connect the cable’s drain wire to an available chassis (earth)
ground at the controller. RKI controllers typically have a ground stud that can be used
to ground the cable’s drain wire.
Cable Shield
Amplifier (Transmitter)
White
Green
Detector Wires
Controller or
Recording Device
4 - 20 mA In (S)
+ 24 VDC
- (DC Ground)
Amplifier
J-Box
Red
W
LE
L
G
R
S
Black
B
P
W
R
/
S
IG
