35-3010RK-06-02 Sample-Draw Detector • 1
Overview
This manual describes the 35-3010RK-06-02 sample-draw detector. This manual also
describes how to install, start up, maintain, and calibrate the detector. A parts list at the
end of this manual lists replacement parts and accessories for the sample-draw detector.
Specifications
Table 1 lists specifications for the 35-3010RK-06-02.
WARNING: When using the 35-3010RK-06-02, you must follow the instructions and
warnings in this manual to assure proper and safe operation of the
35-3010RK-06-02 and to minimize the risk of personal injury. Be sure to
maintain and periodically calibrate the 35-3010RK-06-02 as described in
this manual.
Table 1: Specifications
Target Gases & Detection Ranges Oxygen: 0-25% volume
Carbon Monoxide (CO): 0 - 300 ppm
Carbon Dioxide (CO
2
): 0 - 5,000 ppm
Input Power 24 VDC
Current Draw 200 mA
Output Signals CO channel: 4-20 mA
Oxygen and CO
2
channels: direct connect
Construction (housing) Fiberglass/polyester (NEMA 4X)
Dimensions 15.44 in. H x 12.55 in. W x 8.31 in. D
Weight 14 lbs.
Sampling Method Sample-draw
Sample Flow 1.2 SCFH (nominal)
Response Time 90% in 30 seconds
Accuracy Oxygen:
± 0.5% O
2
Carbon Monoxide:
± 5% of reading or ± 5 ppm CO (whichever is greater)
Carbon Dioxide:
± 5% of reading or ± 2% of full scale (whichever is greater)
