Internal Description • 9
•
Displays and resets the minimum and maximum gas concentration
values.
Buzzer
The buzzer is on the bottom of the housing. It is on the far right. The buzzer
sounds audible alarms to warn you of gas alarms and instrument failures.
Internal Description
This section describes the internal components of the Beacon 200.
Buzzer
Controller
Terminal Strip
Alarm Terminal
Strip
AC Fuses
Power Switch
DC Fuse
Alarm Relays
(see Figure 3)
Main PCB
Display PCB
(see Figure 2)
Reset Switch
3/4" Conduit
Hub, 3X
Detector/Transmitter
Terminal Strip, Channel 2
Detector/Transmitter
Terminal Strip, Channel 1
Power
Supply
AC In
Terminal Strip
Figure 1. Beacon 200 Gas Monitor Component Location
