Cleaning, wear and service
32
Fig. 29: Screw securing adhesive
•
Use two new screws (RS) for installation or secure
both screws with liquid screw securing adhesive (RL).
Pos : 12.16 / 0005 R ET SCH/ 0005 RET SCH Bedi enungsanleit ungen Kapitels ammlungen/ BB50/ 0010 R einigung Wart ung Verschl eiß/ 0010 BB50 Modul Br ec hbac ken hi nt en aust ausc hen @ 5\ mod_1346078786485_9.doc x @ 34754 @ @ 1
Fig. 30: Replacing the rear breaking jaw
The rear breaking jaw is replaced directly in the machine. The rear crusher arm
remains in the machine in the process.
•
Unscrew the two screws (RS).
•
Remove the retaining plate (RH)
•
Replace the breaking jaw (RB).
RS
RH
RB
RS
RL
