Specifications
General Specifications:
(Unless otherwise indicated all specifications are rated from a nominal 23 °C, 70 % RH for 1 year from
calibration)
Temperature Range
-25 to 60 °C (-10 to 140 °F)
Relative Humidity Range
10 % ≤RH ≤90 % (0 to 35 °C), Non-condensing
10 % ≤RH≤ 70 % (35 to 60 °C), Non-condensing
Size
4.9 X 3.15 X 1.82 inches (125.5 X 80 X 46.2 mm)
Weight
9.1 oz (258 grams)
Battery
9V Alkaline provides 45 hours of continuous use
Miscellaneous
ontrast graphic liquid crystal display with 0.357” (9.07 mm) high
digits
Low battery indication with nominal 1 hour of operation left
Protection to 60V DC or AC peak up to 30 seconds in duration
High c
RTD Curve Simulation Specifications (ITS-90 Curves):
Accuracy
Typical accuracies for RTD curves
are:
Pt100
Cu10
Ni110, Ni 120
Ω
±(0.015% of Setting in Ω + 0.05Ω)
)
±0.25°C (±0.5°F)
±0.25°C (±0.5°F
±1.5°C (±3°F)
Allowable Excitation Current
100
µA to 10.2 mA, steady or pulsed/intermittent/smart
for accuracies below 100µA add
are in Ω)
±10
µV/Excitation Current (units
Pulsed Excitation Current
Compatibility
DC to 0.01 second pulse widths
Output Dial Adjustment
Resolution
0.1°F or 0.1°C Adjustment Resolution for Model 511
or Model 510
1°C or 1°F Adjustment Resolution f
Temperature Coefficient
±0.05
Ω/°C Ambient
WARRANTY
Our equipment comes with a NIST traceable Certificate and is guaranteed against defective material and workmanship (excluding
batteries) for a period of three years from the date of shipment. Claims under guarantee can be made by returning the equipm
prepaid to our factory. The equipment will be repaired, replaced or adjusted at our option. The liability of Practical Instrument
Electronics (PIE) is restricted to that given under our guarantee. No responsibility is accepted for damage, loss or other expense
incurred through sale or use of our equipmen
ent
t. Under no condition shall Practical Instrument Electronics, Inc. be liable for any
special, incidental or consequential damage.
