Model 510/511

Operating Instructions

841 Holt Road #1 • Webster, NY 14580

Tel: 585-872-9350 • Fax: 585-872-2638

[email protected] • http://www.piecal.com/

Practical Instrument Electronics, Inc. Copyright  2003. All rights reserved.

510/511-9002 2/25/04

3-4

Connection Diagrams

Two Wire Connection to Transmitter

Three Wire Connection to Transmitter

Four Wire Connection to Transmitter
