Operating Instructions
Double Click Menus - MAIN Page
MAIN
> EXIT
FUNCTION
mA
MODE
SOURCE
2W SIM
UNITS
mA
%
HART 250
Ω* ON
OFF
>EXIT
FUNCTION V
RANGE 10V
100mV 1V
> EXIT
FUNCTION
mA
MODE
READ
PWR MEAS
UNITS
mA
%
HART 250
Ω* ON
OFF
Double click the EZ-DIAL knob to access the Double Click
Menus. Shown are the
MAIN menus for each function. Turn the
knob to scroll thru the menus and press the knob to select.
Available choices are shown in grey.
>EXIT
FUNCTION V
RANGE 10V
1V 60V
100mV
Source mA & Simulate 2 Wire Transmitters
Read mA, Power/Measure Transmitters
& Leak Detect
Source V & mV
Read V & mV
> EXIT
FUNCTION
FREQ
RANGE
20KHZ
10000HZ 1000HZ 2000CPM
Source & Read Frequency
> EXIT
FUNCTION
pH
Source pH
* Hart 250Ω only appears
in 4-20 mA operation
