Features
■
Ground checkout safety stop
■
Secondary shorting plug — allows removal when unit is mounted
■
Telemetry signal release verification
Overlap TEE Self-Deployer
Model 1/2 OL-SD
2.812
2.90
2.35
.38
2.250
2.208
1.04
R
1.50
2.312
.250
1.750
.250
1.0
3.250
All dimensions are in inches
unless otherwise noted
