Features
■ Automatic full-extend and -retract motor power cut-off
■ Full-extend and -retract flags
■ Deployed length indicator
■ Minimal magnetic materials
■ Rear-mounting configuration shown
■ Removable RF test enclosure with connector
■ CFE pre-amp attachment
■ Deployed TEE alignment to within 0.1 degree
Hingelock TEE Deployer
Model 9843
3.00
.38
.25
6.25
2.06 3.03 1.31
8.23
7.20
6.62
11.25
3.38
2.69
20.06
15.06
2.06
4.23
6.14
7.10
5.13
4.41
2.25 1.812
All dimensions are in inches
unless otherwise noted
