7. Technical Data TalkBox
Waveforms Up to 15 different signals •
Waveforms can be added / changed by the user •
Factory signal set •
NTi Audio STIPA Test Signal (TNO verified), Reference Speech
Signal, White Noise, Pink Noise, Delay Test Signal, Sine 1 kHz
Line Out XLR, balanced 100 Ohm, unbalanced 50 Ohm •
Maximum output level: +18 dBu, •
1 kHz file with 60 dB @ 1 meter: typically -11 dBu
Line Input XLR, balanced 38 kOhm •
Max. input level: +18 dBu (acc. to EBU R68, ITU-R rec. 645) •
Internal delay from XLR input to speaker: 59 ms •
CF-Card 256 MB included, FAT32 formatted, NTi Audio # 600 000 087 •
Wav-file format: 16 Bit, 44.1 kHz mono •
Acoustical Flatness STIPA band levels (in axis): • typ < +/- 0.5 dB @ 24°C
• typ < +/- 1.0 dB @ 10°C - 30°C
Acoustical Output Level STIPA: 60 dBA •
SPL
@ 1 m +/- 0.5 dB, acc. to IEC60268-16
STIPA band sensitivity gradient: - 0.07dB / °C (average) •
Others see track list in user manual •
Power Supply 10 - 18 VDC, 10 Watt •
External switching power supply included (110 V .. 240 V) •
External Mute Jack 3.5 mm (1/8“), floating switch required
Mounting Mic Stand 5/8” with Adapter to 3/8”
Dimensions (LxWxH) 150 x 150 x 175 mm (5.9 x 5.9 x 6.9 inch)
Weight 3.5 kg
Operating Temperature 0° to +45° C (32° to 113° F)
