NTi Audio TalkBox - Manual (Page 11)

10 11
Play LED
The green Play LED indicates the following:
continuously
on
The audio signal is replayed •
At Line In mode (= Select Track switch set to “0” ) and input •
signal > -30 dBu
flashing Error indication, which might be caused by
The CF-Card is not plugged in or damaged •
The file “serialnumber_xxx.cal” is not found on the card •
The selected audio file is not available, damaged or of wrong •
format
Select Track Switch
This switch allows the following selections:
“0”
This position selects the input signal from the input connector
“Line In” to the speaker.
“1” - “F” These positions select the individually stored audio tracks from
the CF-Card in hex-order form (1, ... , 9, A, B, C, D, E, F).
Clip LED
The red Clip LED is activated when the Line In mode is selected
(
= Select Track switch set to “0”) . Reduce the input level when the Clip LED flash-
es.
