Crimp pin 3,6 mm, machined ....16 mm

2

(AWG 6) ......................7.015.953.631

Crimp socket 3,6 mm, machined..16 mm

2

(AWG 6) ......................7.015.953.632

For appropriate setting of crimp tool see page 148

Crimp Tool Settings see page 144

Power Connectors Size 1,5 (M 40) / Contacts

Contacts

Type

Part Number
