Insert for pins 2 + 3 + PE.....................................................2 x crimp pins 2 mm
...................................................................................... 4 x crimp pins 3,6 mm
Insert for sockets 2 + 3 + PE ................................................2 x crimp sockets 2 mm
...................................................................................... 4 x crimp sockets 3,6 mm
Insert for pins 4 + 3 + PE.....................................................4 x crimp pins 2 mm
...................................................................................... 4 x crimp pins 3,6 mm
Insert for sockets 4 + 3 + PE ................................................4 x crimp sockets 2 mm
...................................................................................... 4 x crimp sockets 3,6 mm
Type of Contact Contact Arrangement, Mating View
Power Connectors Size 1,5 (M 40) / Required Contacts
