139
Snapflex 25.......................7.010.900.214
DN 23 ..............................7.010.900.215
Snapflex 32.......................7.010.900.216
DN 29 ..............................7.010.900.217
Type Part Number Accessories
Dimensions and specifications may be changed without prior notice
Power Connectors Size 1,5 (M 40) / Accessories
Adaptor flange
for Straight Connectors .....................................................7.010.900.129
Adapter for Conduit Fittings
Crimp tool for manual crimping
of machined crimp contacts up to 10 mm
2 (AWG 8)
for power connectors ........................................................7.000.900.902
Crimp tool for manual crimping
of machined crimp contacts 16 mm
2 (AWG 6) ......................7.000.900.903
See page 142 / 143 for crimp tool instructions and page 144 for proper setting
See page 140 / 141 for crimp tool instructions and page 144 for proper setting
