111,2
Ш 46
40 38
111,2
Ш 46
40 38
132
V
+ -
U W
V
+ -
U W
1 2
40 38
118
M 40 x 1,5
V
- +
W U
40 38
118
M 40 x 1,5
V
- +
W U
2 1
Dimensions and specifications may be changed without prior notice
Contacts page 136 • Assembly instructions page 145
Contacts page 136 • Assembly instructions page 145
Contacts page 136 • Assembly instructions page 145
Straight Connector, Female Thread
Straight Connector, Male Thread
Straight Connector, Male Thread
Cable-Ø Part Number
Cable-Ø Part Number
Cable-Ø Part Number
Contacts page 136 • Assembly instructions page 145
Cable-Ø Part Number Straight Connector, Female Thread
Power Connectors Size 1,5 (M 40)
2 + 3 + PE, insert for sockets
13 – 18 mm (.51 – .71“) .....7.710.623.000
17 – 24 mm (.67 – .97“) .....7.710.723.000
21 – 28 mm (.83 – 1.10“) ...7.710.823.000
4 + 3 + PE, insert for sockets
13 – 18 mm (.51 – .71“) .....7.710.643.000
17 – 24 mm (.67 – .97“) .....7.710.743.000
21 – 28 mm (.83 – 1.10“) ...7.710.843.000
2 + 3 + PE, insert for pins
13 – 18 mm (.51 – .71“) .....7.720.623.000
17 – 24 mm (.67 – .97“) .....7.720.723.000
21 – 28 mm (.83 – 1.10“) ...7.720.823.000
4 + 3 + PE, insert for pins
13 – 18 mm (.51 – .71“) .....7.720.643.000
17 – 24 mm (.67 – .97“) .....7.720.743.000
21 – 28 mm (.83 – 1.10“) ...7.720.843.000
