New Era Pump Systems Inc.
www.SyringePump.com
Model NE-300 Syringe Pump
Publication #1200-01 10 08/27/14
9.2 Troubleshooting and Maintenance
Maintenance: Periodically, a small amount of all-purpose oil should be applied to the guide rods.
The mechanism should be kept clean to prevent impeded operation.
No other special maintenance or calibrations are needed
Pusher block makes a snap or click sound when the pump is started: This is a normal condition. When
the pusher block is manually moved, the drive-nut may not have been fully engaged on the drive screw. The
sound heard is the drive-nut engaging on the drive screw.
9.3 Specifications
Mechanical & Electrical
Syringe sizes: Up to 60 mL. 140 mL partially filled.
Number of syringes: 1
Motor type: Step motor
Motor steps per revolution: 400
Micro-stepping: 1/8 to 1/2 depending on motor speed
Advance per step: 0.2126 µm to 0.8504 µm depending on motor speed
Motor to drive screw ratio: 15/28
Drive screw pitch: 20 revolutions/”
Power connector: 2.1 mm, center positive, DC
Voltage at power connector: 12V DC at full load
Amperage: 750 mA at full load
Power supply type: External wall adapter, country and power source specific
Power supply output rating: 12V DC @ 800 mA (or greater if regulated power supply)
Dimensions: 8 3/4” x 5 3/4” x 4 1/2” (L x W x H)
(22.86 cm x 14.605 cm x 11.43 cm)
Weight: 3.6 lbs. (1.63 kg)
Operational
Accuracy Within +/- 1% over length of syringe,
exclusive of syringe variations.
Reproducibility +/- 0.1%
Maximum speed:
3.7742 cm/min
Minimum speed: 0.004205 cm/hr
Maximum pumping rate: 1257 mL/hr with a B-D 60 mL syringe
Minimum pumping rate: 0.73 µL /hr with a B-D 1 mL syringe
Maximum force: 35 lbs. at minimum speed, 18 lbs. at maximum speed
Syringe inside diameter range: 0.100 to 50.00 mm
9.4 Custom Applications
For specialized and OEM applications, contact your dealer
or New Era Pump Systems Inc. Custom modifications can
be made to the mechanics or the firmware.
