LT12D50B LIGHT TOWER • PARTS MANUAL — REV. #0 (03/13/09) — PAGE 27
FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 29676 FUEL TANK ASSY. ................................................................ 1 ............... INCLUDES ITEMS W/#
2# 29605 FUEL TANK 1
3# 29694 CAP, FUEL TANK W/LANYARD 1
4 29992 STRAP, FUEL TANK 1
5# 19633 BUSHING, FUEL 3
6# 12006 FITTING, 90° 1
7# 20795 VALVE, SHUTOFF 4MBARB X 6SBARB SCREEN 1
8# 19661 VALVE, SHUTOFF 5BARB X 6SBARB NO SCREEN 1
9 13211 WASHER, FLAT 1/2 USS 2
10 10176 NUT, NYLOCK 1/2-13 2
11 22066 CLAMP, STEPLESS EAR 3/16 HOSE #123 4
12 60028 HOSE, FUEL RETURN .312 ID SAE J30R7 AR 1PC = 1 FT.
13 60004 HOSE, FUEL LINE .187 I.D. SAE J30R7 AR 1PC = 1 FT.
