LT12D50B LIGHT TOWER • PARTS MANUAL — REV. #0 (03/13/09) — PAGE 19
WINCH ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1# DL205167 BOLT 1
2# DL205055 WASHER 1
3# DL404409 PAWL 1
4# DL404166 SPACER 2
5# DL204363 SPRING 1
6# DL5240387 GEAR COVER, PAINTED BRONZE 1
6# DL5240403 GEAR COVER, PLATED 1
8# DL304755 REEL 1
9# DL304221 ROPE CLAMP KIT 1
12# DL204808 REEL SPACER 1
13# DL404891 BASE 1
14# DL204803 NUT 2
15# DL404579 LOCKOUT LEVER 1
16# DL204364 SPRING 2
17# DL205127 BOLT 1
18# DL204009 BUSHING 1
19# DL205116 E-RING 1
20# DL304760 DRIVE SHAFT 1
21# DL204362 PRESSURE PLATE 1
22# DL404164 RATCHET WHEEL 1
23# DL404163 PRESSURE WASHER 1
24# DL206328 BUSHING 1
25# 29793 HANDLE 1
26# DL205033 NUT 1
27 29790 WINCH ASSEMBLY 1500A D-L .............................1 .........INCLUDES ITEMS W/#
