LT12D50B LIGHT TOWER • PARTS MANUAL — REV. #0 (03/13/09) — PAGE 17
MAST RAISE/LOWER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 0205 SCREW, HHC 3/8-16 x 1 IN. PLATED 3
2 10136 WASHER, FLAT 3/8 IN. 3
4 21781 NUT, FLANGED 3/8-16 SERRATED, PLATED 3
5 1135 SNAP RING 2
6 29008 PIN, SWAGE BALL SOCKET 1
7 29017 SCREW, HHC 1/2-13 x 5.5 IN. 1
8 29018 SPACER, .75 OD x .5 ID x 1.59 IN. 2
9 29016 GUIDE, WIRE ROPE 2
10 29155 SHEAVE, 2 OD x .5 IN. ID 1
11 10176 NUT, NYLOC 1/2-13 IN. 1
12 29077 SCREW, HHC 5/8-11 x 9.5 IN. 1
13 29481 STOP, MAST THRUST SPRING 1
14 19989 SPRING, TOWER 1
15 9503 NUT, NYLOC 5/8-11 IN. 1
16 29033 TOWER, LOCK 1
17 19012 LOCK PIN 5/16 x 2 IN. QUICK RELEASE 1
18 29482 SPRING, .468 OD x 2.13 IN. 1
19 20276 PIN, ROLL 1/4 x 1.75 IN. 1
20 0183 PIN, COTTER 1/8D x 1-1/4 IN. 1
21 19996 LANYARD 1
23 1450 WASHER, FLAT SAE #6 1
