PAGE 42 — DCA-45SSIU2 — OPERATION AND PARTS MANUAL (STD) — REV. #7 (06/13/07)
Figure 54. Voltage Adjust Control Knob
Figure 55. Ammeter (No Load)
13. The ammeter (Figure 55) will indicate zero amps with no
load applied. When a load is applied, this meter will
indicate the amount of current that the load is drawing
from the generator.
DCA-45SSIU2 — GENERATOR START-UP PROCEDURE
10. The generator's frequency meter (Figure 52) displays
the 60 cycle output frequency in HERTZ.
11. The generator's voltage meter (Figure 53) displays the
120 VAC in VOLTS. If the voltage is not within the specified
frequency tolerance,
Figure 53. AC Voltmeter
Figure 52. Frequency Meter (Hz)
12. Use the voltage adjustment control knob (Figure 54) to
increase or decrease the desired voltage.
5. Push the engine throttle control lever inward (Figure 48)
to the “LOW ” position.
Figure 48. Engine Throttle Control Lever (Low)
6. Preheat the engine glow plugs by turning the ignition
key (Figure 49) to the “PRE-HEAT” position.
Figure 50. Pre-Heat Indicator Lamp
8. Let the engine idle for 3-5 minutes, listen and check for
any abnormal sounds or smells. Check for fuel leaks,
and noises that would associate with a loose cover or
harware. If any of the above mentioned conditions exists,
shut-down the engine and correct the problem.
9. If the engine is running smoothly with no problems, pull
and place the engine throttle lever (Figure 51) in the
“HIGH ” position”.
7. When the preheat lamp luminates (Figure 50), turn the
ignition key to the “START” position. Once the engine
starts, release the ignition key and allow it to return to
the “OPERATION” position (Figure 49).
Figure 51. Engine Throttle Control Lever (High)
Figure 49. Ignition Switch (Pre-Heat Position)
