page 12 — DCa25Usi2 60 hz generator • operation anD parts manUal — rev. #1 (02/28/14)
SpEcIfIcatIOnS
table 1. Generator Specifications
model DCA25USI2
Type
Revolving field, self ventilated,
drip-proof, single-bearing generator
Armature Connection Star with Neutral Zigzag
Phase 3 Single
Standby Output 27.5 kVA (22.0 KW) 15.8 KW
Prime Output 25kVA (20 KW) 14.4 KW
Power Factor 0.8 1.0
voltage 240 or 480V 240V/120V
Frequency 60 Hz
Speed 1800 rpm
aux. aC power Single Phase, 60 Hz
aux. voltage/output 4.8 Kw (2.4 kW x 2)
Dry Weight 1,808 lbs. (820 kg.)
Wet Weight 2,132 lbs. (967 kg.)
table 2. Engine Specifications
model ISUZU BV-4LE2
Type 4 cycle, water-cooled, direct injection
no. of Cylinders 4 cylinders
Bore x stroke 3.35 in. x3.78 in. (85 mm x 96 mm)
Displacement 132 cu. in. (2,179 cc)
Rated Output 30.6 HP at 1800 rpm
Starting Electric
Coolant Capacity 1.7 gal. (6.4 liters)
lube oil Capacity 2.25 gal. (8.5 liters)
Fuel Type #2 Diesel Fuel
Fuel Tank Capacity 41.7 gal. (158 Liters)
Fuel Consumption
1.66 gal. (6.3 L)/hr at full load 1.21 gal. (4.6 L)/hr at 3/4 load
0.85 gal. (3.2 L)/hr at 1/2 load 0.58 gal. (2.2 L)/hr at 1/4 load
Battery 12V-53 Ah x 1
