Sg1400C3 STudio generaTor • operaTion and parTS manual — rev. #1 (02/15/12) — page 103
no. parT no. parT name QTY. remarKS
1 EE47423 MANIFOLD, HYD. ACTUATORS, 150 PSI 1
2 EE41126 TEST FITTING, PRESSURE GAUGE 1
3 EE41837 CONN, DIN, PROPORTIONAL, SOLENOID 1
4 EE47425 BRACKET, HYD. ACTUATOR MANIFOLD 1
5 SCREW, PAN HD, 10/32" .................................................... 4 .................OBTAIN LOCALLY
6 WASHER, FLAT, 10/32" ...................................................... 4 .................OBTAIN LOCALLY
7 NUT, NYLOCK, 10/32" ........................................................ 4 .................OBTAIN LOCALLY
8 BOLT, HX HD, 1/4" x 1-1/2" ................................................. 2 .................OBTAIN LOCALLY
9 WASHER, FLAT, 1/4" .......................................................... 4 .................OBTAIN LOCALLY
10 NUT, NYLOCK, 1/4" ............................................................ 2 .................OBTAIN LOCALLY
11 6802-08-06-NWO ELBOW, 45°, 1/2"MJ x 3/8"MAORB 1
12 30-255 BARB, 45° SAE FLARE FEMALE SWIVEL 1/2" x 1/2" 3
13 10-300 ELBOW, 90°, 1/2" x 1/2" MALE FLARE x MALE NPTF 2
15 EE18072 VALVE, LOCKING BALL, BRASS, 1/2"FNPT 1
16 28-214 FITTING, HX NIPPLE, 1/2"NPTF 1
17 28-027 TEE, UNION, 1/2"NPTF 1
18 28-225 FITTING, REDUCING HX NIPPLE, 3/4" x 1/2"NPTF 1
19 28-249 TEE, STREET, 3/4"NPTF 1
20 37982-8-8 BARB, SAE 90° SWIVEL HB 1
21 HOSE, INSTAGRIP, 1/2" 300SIWP FLAME .......................AR ...............OBTAIN LOCALLY
RESISTANT USMSHA 2G-1C-14C/33 GOODYEAR
22 6801-08-06-NWO ELBOW, 90°, 1/2"MJ x 3/8"MAORB 1
23 6801-06-06-NWO ELBOW, 90°, 3/8"MJ x 3/8"MAORB 2
24 3/8SAE100R2-AT160 HOSE, HYD., 3/8" x 160" MANIFOLD to 3-WAY VALVE 1
hyD. ManifOLD, vaLvE anD hOSE aSSy.
