FRAME ASSY.
SFCS-16
OPERATION AND PARTS MANUAL REV #3 (02/23/06)
PAGE 45
FRAME ASSY.
NO. PART
NO. PART
NAME QTY. REMARKS
20
SFCS87061800
BOLT, CARRIAGE 3/8-16 UNC X 2-1/4” PLATED
2
21
SFCS55050600
SCREW, BUTTON HEAD 5/16-18 UNC X 3/4” PLATED
2
22
SFCS160311
MOUNT, RUBBER ASSY. ..................................................... 4............ S/N 26797~ABOVE
............................................................................................... .............. INCLS. ITEMS W/#
23
SFCS15060800
SCREW, CAP 3/8-16 UNC X 1”, PLATED ............................. 4............ S/N 26814~BELOW
23
SFCS15060800
SCREW, CAP 3/8-16 UNC X 1”, PLATED ............................. 12.......... S/N 26815~ABOVE
24
SFCS16060000
WASHER, LOCK 3/8”, PLATED ............................................ 4............ S/N 26814~BELOW
24
SFCS16060000
WASHER, LOCK 3/8”, PLATED ............................................ 16.......... S/N 26815~ABOVE
25 SFCSSP80430
BEARING,
FLANGE
1
26
SFCS53050000
NUT, HEX., NYLOCK 5/16-18 UNC, PLATED
2
27
SFCS15050800
SCREW, CAP 5/16-18 UNC X 1”, PLATED
2
28
SFCS43060000
NUT, WING 3/8-16 UNC, PLATED
2
29 SFCS160210
PIN/LANYARD
ASSY.
2
30
SFCS15050600
SCREW, CAP 5/16-18 UNC X 3/4”, PLATED
4
31 SFCS160220
BAR,
STOP
2
32 SFCS160300
GROMMET
2
33
SFCS160260
T-HANDLE HEX KEY 3/16”
1
34
SFCS20031000
PIN, ROLL 3/16 X 1-1/4”
2
35 SFCS160200
TUBE,
HANDLE
1
36 SFCSKIC172
RING,
KICK
OUT ................................................................... 2............ S/N 25550~ABOVE
37#
SFCS160311020
CUP RUBBER MOUNT ......................................................... 8............ S/N 26797~ABOVE
38 SFCS160310
MOUNT, RUBBER................................................................. 4............ S/N 26796~BELOW
38# SFCS160311010
MOUNT,
RUBBER................................................................. 4............ S/N 26797~ABOVE
39
SFCS15050900
SCREW, CAP 5/16-18 UNC X 1-1/8” PLATED ...................... 2............ S/N 26815~ABOVE
40 SFCSSG120130 CONNECTOR,
GREASE ....................................................... 1............ S/N 26815~ABOVE
41
SFCSSG120120
CONNECTOR, GREASE 1/8” PIPE....................................... 1............ S/N 26815~ABOVE
42
SFCS160380
HOSE GREASE, 5/32” CLEAR (11” LENGTH)...................... 1............ S/N 26815~ABOVE
43
SFCS80590
FITTING, GREASE, STRAIGHT ............................................ 1............ S/N 26815~ABOVE
44 SFCS160370
BAR,
STAND-OFF ................................................................. 2............ S/N 26815~ABOVE
45
SFCS49060000
WASHER, FENDER 3/8” X 1-1/2”.......................................... 8............ S/N 26796~BELOW
46#
SFCS18060000
NUT, HEXAGON, 3/8-16, UNC, PLATED
2
47#
SFCS16060000
WASHER, LOCK 3/8”, PLATED
2
48
SFCS60050300
SCREW, CAP 5/16-18 UNC X 3/8” PLATED
2
