ADJUSTABLE AXLE ASSY.
SFCS-16 OPERATION AND PARTS MANUAL REV #3 (02/23/06) PAGE 39
ADJUSTABLE AXLE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 SFCS160060 AXLE 1
2 SFCS160130 AXLE ARM ASSY. 1
3 SFCS160050 SCREW, JACK 1
4 SFCS21020800 PIN ROLL, SPRIAL 1/8”X1” 1
5 SFCS160240 WHEEL 8” 2
6 SFCS5500590 FITTING GREASE 1
7 SFCS6600410 BUSHIG, BRONZE 3/4” ID 4
8 SFCS62122400 BOLT, SHOULDER 3/4”X3” 2
9 SFCS200682 WASHER, FIBER 2
10 SFCS62121200 BOLT, SHOULDER 3/4”X1-1/2” 2
11 SFCS18100000 NUT, HEX 5/8-11 UNC, PLATED 3
12 SFCS17100000 WASHER, FLAT 5/8” PLATED 2
13 SFCS160090 SCRAPER, WHEEL 2
14 SFCS17050000 WASHER, FLAT 5/16” PLATED 2
15 SFCS16050000 WASHER, LOCK 5/16” PLATED 2
16 SFCS55050600 SCREW, BUTTON HEAD 5/16” UNCX3/4” PLATED 2
