FRAME ASSY.
SFCS-16 OPERATION AND PARTS MANUAL REV #3 (02/23/06) PAGE 43
FRAME ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 SFCS160010 FRAME .................................................................................... 1............ S/N 26814~BELOW
1 SFCS160011 FRAME .................................................................................... 1............ S/N 26815~ABOVE
2 SFCS160170 COVER, MOTOR 1
3 SFCS160230 BLOCK, WEIGHT 1
4 SFCS160020 PLATE, ORBITAL.................................................................... 1............ S/N 26814~BELOW
4 SFCS160022 PLATE, ORBITAL.................................................................... 1............ S/N 26815~ABOVE
5 SFCS160190 PLATE, CLAMPING 1 S/N 27104~BELOW
5 SFCS160191 PLATE, CLAMPING 1 S/N 27105~ABOVE
6 SFCS160110 PLATE, BOTTOM 1 S/N 26814~BELOW
6 SFCS160111 PLATE, BOTTOM.................................................................... 1............ S/N 26815~ABOVE
7 SFCS160100 BLOCK, BEARING .................................................................. 1............ S/N 26814~BELOW
7 SFCS160101 BLOCK, BEARING .................................................................. 1............ S/N 26815~ABOVE
8 SFCS160030 MOTOR ELECTRIC 3/4HP 115 VOLT .................................... 1............ S/N 26814~BELOW
8 SFCS160031 MOTOR ELECTRIC 3/4HP 115 VOLT .................................... 1............ S/N 26815~ABOVE
9 SFCS160330 BEARING, SUPPORT ............................................................. 1............ S/N 26814~BELOW
9 SFCS160331 BEARING, SUPPORT ............................................................. 1............ S/N 26815~ABOVE
10 SFCS15050700 SCREW, CAP 5/16-18 UNCX7/8” PLATED 4
11 SFCS16050000 WASHER, LOCK 5/16, PLATED 10
12 SFCS17050000 WASHER, FLAT 5/16", PLATED ............................................. 4............ S/N 25549~BELOW
12 SFCS17040000 WASHER, FLAT 1/4", PLATED ............................................... 4............ S/N 25550~ABOVE
13 SFCS48050800 SCREW, CAP SELF TAP 5/16-18 UNC X 3/4” PLATED 10
14 SFCS86060000 NUT, HEX, FLANGE 3/8-16, UNC, PLATED........................... 8............ S/N 26814~BELOW
14 SFCS18060000 NUT, HEXAGON, 3/8-16, UNC, PLATED................................ 8............ S/N 26815~ABOVE
15 SFCS18060000 NUT, HEXAGON, 3/8-16 UNC, PLATED................................. 2............ S/N 26814~BELOW
15 SFCS86070000 NUT, HEXAGON, FLANGE 7/16”-14 UNC, PLATED .............. 2............ S/N 26815~ABOVE
16 SFCS160320 BEARING, 2 BOLT FLANGED ................................................ 1............ S/N 26814~BELOW
16 SFCS160321 BEARING, 2 BOLT FLANGED ................................................ 1............ S/N 26815~ABOVE
17 SFCS160070 HUB, OFFSET......................................................................... 1............ S/N 26814~BELOW
17 SFCS160071 HUB, OFFSET......................................................................... 1............ S/N 26815~ABOVE
18 SFCS15060800 SCREW, CAP 3/8-16 UNC X 1” PLATED................................ 2............ S/N 25549~BELOW
18 SFCS60060800 SCREW, SOCKET HEAD 3/8-16 UNC X 1” PLATED ............. 2............ S/N 25550~26814
18 SFCS60071000 SCREW, SOCKET HEAD 7/16-14 UNC X 1-1/4” PLATED ..... 2............ S/N 26815~ABOVE
19 SFCS63031000 KEY, SQUARE 3/16” X 1-1/4” ................................................. 1............ S/N 26814~BELOW
19 SFCS63030800 KEY, SQUARE 3/16” X 3/16” X 1” ........................................... 1............ S/N 26815~ABOVE
