SPECIFICATIONS
SFCS-16 OPERATION AND PARTS MANUAL REV #3 (02/23/06) PAGE 34
Specifications
FRAME
STRUCTURE................................................................................. Unitized, Welded Steel Plate
DRIVE SYSTEM ........................................................................... Random 0rbit, Direct Shaft Mount.
NUMBER OF ELASTOMERIC RUBBER MOUNTS ..................... 4
WIDTH ........................................................................................... 14-1/2 inches (368 mm)
WIDTH (AT OPERATOR HANDLE) .............................................. 23 inches (584 mm)
LENGTH (HANDLE FOLDED) ..................................................... 24 inches (610 mm)
LENGTH (OPERATING CONFIGURATION) ................................ 34 inches (864 mm)
HEIGHT (HANDLE FOLDED) ...................................................... 23 inches (584 mm)
HEIGHT (MAXIMUM HANDLE EXTENSION................................ 42inches (1067 mm)
GENERAL
WEIGHT (WITH EXTERNAL WEIGHT
LESS BLADE)................................................................................ 130 lbs (59 kg)
EXTERNAL WEIGHT, EACH ........................................................ 14 lbs (6 kg)
NUMBER OF BLADE OSCILLATIONS ......................................... 1725 PER MINUTE
ELECTRIC MOTOR 3/4 hp, 1725 RPM, 10.3 full loaded amperes @ 115 VAC, 60 Hz, thermally protected.
The electric motor requires a clean (no other electric products on the same circuit) 15 ampere capacity circuit to
properly function. The motor can be wired to also operate from a 230 VAC, 60 Hz, power source. Contact the
Customer Service Department for specific information.
