NEVER stop the engine while cutting at high speeds, except in
case of an emergency. This can damage your Cutter 3 CE Saw.
CAUTI
CAUTI
CAUTI
CAUTI
CAUTION
Adjusting the Handle Bars
STOW CUTTER 3 CE SAW — INSPECTION - ADJUSTMENTS
1.
Loosen the height adjustment bolts (Figure 19) on the handle
bars until the handle bars can freely pivot.
The Cutter 3 CE has adjustable height handle bars. Before
operating the saw, adjust the handle bar height to a comfortable
working position:
To avoid losing control of the Cutter 3 CE saw, be sure to fully
tighten the adjustment bolts before operating the saw to prevent
the bolts from loosening during cutting.
CAUTI
CAUTI
CAUTI
CAUTI
CAUTION
Figure 19. Handle Bar Adjustment Bolts
2. Move the handle bars (Figure 20) up or down to operators
desired preference.
3. Tighten the height adjustment bolts to secure the handle bars
in place.
Figure 20. Handle Bar Height Adjustment
Adjusting the Blade Height
The Cutter 3 CE saw uses a manual
raise/lower crank handle
located on the console with clockwise rotation providing lowering
action, and counter-clockwise rotation providing raising and
lowering action (Figure 21).
To adjust the blade height:
1. Pull upward on the raise/lower crank handle knob.
2. Rotate the crank handle clockwise to
lower the blade
.
Rotate the crank handle counter-clockwise to
raise the
blade
(Figure 21). The handle will stop rotating when the
blade has been fully raised or lowered.
When preparing to cut, your blade size determines the depth
of the cut. See Table 7 to determine the proper blade size for
your required cutting depth.
NOTE
When moving the saw around
between cutting, fully raise the blade
to avoid striking the ground with the
blade.
Figure 21. Blade Height Adjustment
