SP7060 SERIES MULTIQUIP SAW — PARTS MANUAL — REV. #5 (05/06/11)— PAGE 77
30", 36" BlaDEGuarD assY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1@
200012
BLADEGUARD W/A, 30" REAR HALF
1
1#
200014
BLADEGUARD W/A, 36" REAR HALF
1
2
*
200011
BLADEGUARD W/A, 30" FRONT HALF
1
2#
200013
BLADEGUARD W/A, 36" FRONT HALF
1
3@# 582039
BUSHING, BLADEGUARD HINGE DELRIN
1
4@# 37395
MANIFOLD, WATER LARGE
1
5@# 200019
FLAP,MUD BLADEGUARD .......................................1 ................... SAFETY ITEM
6@# 0131 A
SCREW, HHC 1/4 - 20 X 3/4
1
7@# 26250
SCREW, HHC 1/4 - 20 X 1-3/4
2
8@# 06503-030
SCREW, HHC 1/2 - 13 X 3-3/4
1
9@# 10176
NUT, NYLOC 1/2-13
1
10@# 10024
NUT, NYLOC 1/4-20
3
11@# 10930
WASHER, FENDER 1/4 X 1-1/4
1
12@# 370456
FITTING, BRASS 6BARB-1/4MP
2
13@# 2113
FITTING, PLUG 1/8MP HEX SKT HD
1
14@# 37396
3/8" QC MALE
1
15@# 1618
NUT, NYLOC 10-24
2
16@# 923144
SCREW, SHC 10-24 X 1/2
2
17@# 22129-001
PIPE STRAP 3/8
2
18@ 37509
HOSE, WATER #6 LP, 30" BLADEGUARD
2
18#
37510
HOSE, WATER #6 LP, 36" BLADEGUARD
2
19
BG3000
GUARD, 30" STREETPRO 3/6/7 STD FLANGE .......1 ................... SAFETY ITEM
........................................................................................................ INCLUDES ITEMS W/@
........................................................................................................ CONTACT MQ UNIT SALES
19
BG3600
GUARD, 36" STREETPRO 3/6/7 STD FLANGE .......1 ................... SAFETY ITEM
........................................................................................................ INCLUDES ITEMS W/#
........................................................................................................ CONTACT MQ UNIT SALES
