SP7060 SERIES MULTIQUIP SAW — PARTS MANUAL — REV. #5 (05/06/11)— PAGE 49
lIFt BaIl assY.
NO. PART NO. PART NAME QTY. REMARKS
1 37114 SPACER, DEUTZ ENGINE LIFTING BRACKET 1
2 37115 BRACKET, DEUTZ ENGINE LIFTING ......................1 ................... SEE NOTE BELOW
3 940694 SCREW, HHC M10 - 1.5 X 30MM FT 10.9 NP 1
4 37314 SCREW, HHC M12 - 1.75 X 120MM TAP BOLT 1
5 37315 SCREW, HHC M12 - 1.75 X 120MM 10.9 NP 1
6 940358 WASHER, M10 X 21MM ZINC 1
7 933244 WASHER, FLAT SAE 1/2 GRD 9 YZ 3
8 933241 WASHER, FLAT SAE 5/16 GRD 9 YZ 1
9 16083 NUT, HEX M12 - 1.75 NO PLATE 1
10 06500-007 SCREW, HHC 5/16 - 18 X 7/8 1
NOTICE
Type 2 Rope Guide System supercedes Type 1 Rope
Guide System. See Front Pointer Assy.
