SP7060 SERIES MULTIQUIP SAW — PARTS MANUAL — REV. #5 (05/06/11)— PAGE 29
FuEl assY.
NO. PART NO. PART NAME QTY. REMARKS
1 19473 CLAMP, HOSE WORM # 2 6
2 19633 BUSHING, RUBBER FUEL DAPCO 10672 4
3 29509 CAP, FUEL TANK 2.25 DIA, ONE WAY VALVE 1
4 35022 CLAMP, LOOP CUSHIONED #8 1
5 37128 BALL VALVE, 90 W/SCREEN #6,DAPCO 12862 1
6 37191 FUEL TANK 1
7 37498 FUEL LINE 30R7 5/16 X 12 12”
8 37500 FUEL LINE 30R7 5/16 X 40.00 40”
9 37501 FUEL LINE 30R7 1/4” X 64” 64”
10 37502 TUBING, VINYL 1/4 CLEAR 1
11 37809 FILTER, DEUTZ 1178753, IN-LINE 1
12 368006 FITTING, FUEL 90 DEG. #4 X #6 BARB 3
13 37195-353 MOUNT, FUEL TANK 1
14 933242 WASHER, FLAT SAE 3/8 GRD 9 YZ 5
15 0205 SCREW, HHC 3/8 - 16 X 1.0 5
