SP7060 SERIES MULTIQUIP SAW — PARTS MANUAL — REV. #5 (05/06/11)— PAGE 25
DEPtH InDICatOr/stOP sWItCH assY. (nEW stYlE)
NO. PART NO. PART NAME QTY. REMARKS
1 37544 SHAFT, DEPTH INDICATOR 1
2 37545 BUSHING, FLANGED 2
3 37547 SHAFT, IDLER PULLEY 2
4 37548 PULLEY, IDLER 2
5 110031 POINTER, CONCRETE SAW DEPTH 1
6 560025 KNOB, SAW DEPTH INDICATOR 1
7 37549 PULLEY, DUAL GROOVE 1
8 37550 BELT, INDICATOR DRIVE 1
9 0948 WASHER, FLAT SAE 1/4 3
10 37332 RING, 3/16 E-STYLE EXTERNAL 6
11 926149 SCREW, SHDLR 1/4D X 5/16L, 10-24 SCKT HD 1
12 37162 SPRING, EXTENSION 1
13 973752 SCREW, BHSC 1/4 - 20 X 5/8 SS 2
14 37551 HOUSING, DEPTH INDICATOR 1
15 37557 BRACKET, CABLE INDICATOR 1
16 2295 SCREW, HHC 1/4 - 20 X 7/8 1
17 10024 NUT, NYLOC 1/4 - 20 2
18 37401 SCREW, SH SHLDR 1/2-20, 5/16 OD X 1/4 L 1
19 37679 RING, SNAP SH 87 2
20 37678 CABLE ASSY., DEPTH INDICATOR 1
NOTICE
Parts on this page replace those listed on Depth Indica-
tor/Stop Switch Assy. (Old Style)
