PAGE 8 — SV-SERIES VIBRATOR MOTOR— PARTS & OPERATION MANUAL — REV. #2 (09/16/02)
WARNING! WARNING! WARNING! WARNING! WARNING!
When using electric tools, basic safety
precautions should ALWAYS be followed to
reduce the risk of fire, electric shock, and
personal injury.
1. Know your concrete vibrator. Read this instruction manual.
Learn the vibrator's applications, limitations, and specific
potential hazards peculiar to this tool.
2. Guard against electrical shock.
3. Prevent body contact with grounded surfaces. (For example:
pipes, reiforcing bar, etc.)
SV-SERIES VIBRATOR MOTOR— RULES FOR SAFE OPERATION
SAFETY INSTRUCTIONS
For the safety of yourself and others working around you, it is
EXTREMELY important that you observe the following rules:
■ NEVER operate a vibrator motor while under the influence of
drugs, alcohol, or medications that may impair the senses or
reactions.
■ Dress properly. Wear appropriate clothing and protective
safety equipment. Wear clothing that will not likely become
caught in the equipment or snag on the forms. Eye, hand,
hearing, and foot safety equipment is required.
■ Keep untrained personnel away. DO NOT let visitors contact
the vibrator unit. All visitors should be kept away from the
work area.
■ ALWAYS disconnect the motor from the power source when
not in use, before servicing, and when changing flexible
shafting and vibrator heads.
■ DO NOT abuse the motor cord.
■ NEVER carry the motor by the cord. Use the carrying frame.
■ DO NOT yank the cord to disconnect it from the receptacle.
Grasp the plug itself to disconnect it.
■ Keep the cord from heat, oil, and sharp objects.
■ Avoid unintentional starting.
■ DO NOT carry plugged-in motor with finger on the switch.
■ Be sure switch is in the "OFF" position before plugging the
motor into a power source.
■ DO NOT overload the motor. It will do a better and safer job
at the rate for which it was designed.
■ DO NOT expose vibrator motor to rain.
■ DO NOT use vibrator motor in damp or wet locations without
proper electrical circuits.
■ DO NOT use the vibrator in the presence of flammable liquids
or gases.
■ Keep work area well lit.
■ Keep work area clean. A cluttered area invites injuries.
■ DO NOT overreach. Keep proper footing and balance at all
times.
■ Secure forms. Make sure the form work is well made and
braced to withstand the stresses made by vibration.
■ The use of any attachment or accessory not intended for use
with this vibrator motor may present a risk of injury to the
operator or other personnel.
■ Maintain tools with care.
■ Keep vibrator motor clean for better and safer operation.
■ Inspect motor cord periodically and if damaged, have
itrepaired by an authorized service facility.
■ Use only factory authorized identica
l replacement parts .
■ Check for damaged parts.
■ Before each use
ALWAYS check the motor to make certain
there are no damaged parts, and that all parts function
properly, (examples: switch, cord housing). If any damage or
malfunctioning parts are found, have them repaired or
replaced by an authorized service facility.
■ NEVER use the motor with a defective switch. If the switch
does not turn the motor "ON" or "OFF", have it replaced before
using the motor.
■ Before plugging the motor into a power source, ALWAYS
remove any wrenches or other tools from the motor, shaft,
and head that were used for assembly.
■
ALWAYS use the correct tool for the job.
■ DO NOT force the motor and head to do the job of a larger
motor and head.
■ DO NOT use this motor for anything other than its intended
use.
■ Store idle vibrator motor. When not in use, motor should be
stored in a dry, safe storage area.
■ SAVE THESE INSTRUCTIONS. Keep these instructions in
a safe place for future reference.
